Product details
SPECIFICATIONS
Actuator Mode: With Instruction
Certification: CE
EU LVD Voltage: High voltage: Above 50Vac or 75Vdc
High-concerned chemical: none
Material: Brass
Media: Water
Model Number: 2W
NC or NO: Normally Open
Origin: Mainland China
Port Size: 3/8" 1/4" 1/2" 3/4" 1" 1-1/4" 1-1/2" 2"
Power: Solenoid
Power Source: Ac
Pressure: Low Pressure
Standard or Nonstandard: Standard
Structure: Dıaphragm
Temperature of Media: Medium Temperature
Specification
Model NO: 2W Series
Thread: Female (BSP Thread, G Thread, NPT Thread)
Medium: Water, Gas, Oil
Type: Normally Open
Working Voltage: 380VAC, 240VAC, 220VAC, 110VAC, 24VDC, 24VAC, 12VDC.
Working Pressure: 0-10bar
Operation: Direct Acting
Waterproof IP: IP65
Body Material: Brass
Seal: NBR
Medium temperature: -5-80degree
