Product details
SPECIFICATIONS
Actuator Mode: Without Manual And Instruction
Certification: CE
EU LVD Voltage: Low voltage: Below 50Vac or 75Vdc
High-concerned chemical: none
Material: Brass
Media: Water
Model Number: 2W-25K
NC or NO: Normally Open
Origin: Mainland China
Port Size: 1/4"1/2"3/4"1"2"
Power: Solenoid
Power Source: Ac
Pressure: Low Pressure
Seal: NBR
Standard or Nonstandard: Standard
Structure: Dıaphragm
Temperature of Media: High Temperature
medium temperature: -5-80℃
Specification
Model: 2W
Pipe size:1/4, 1/2, 3/4, 1, 2
Thread:BSP, NPT female
Medium: Air water oil, the neutral gas liquid
Type: Normally Opened (opened when de-energizes,closed when energized.)
Working pressure :1-10bar for water, air, 1-7bar for oil
Operating: Pilot operating
Seal: NBR
Voltage: AC240V/AC220V/AC120V/AC110V/AC24V/DC24V/DC12V (tolearance ±10%)
Materail: Brass
Seal:NBR(-5-80degree)
